| 技术参数 | 标称值 | 备注 |
| Technical parameter | Nominal value | Remarks |
| 叉车车体 Forklift body type | 坤厚定制 | |
| 外形尺寸Outline dimension | 1950mmX915mmX2150mm | 长X宽X高 |
| 负载Load | 2000kg | |
| 激光扫描头 Laser scanning head | SICK,HOUKUYO | 80M |
| 激光防撞头 Laser anticollision head | SICK,HOUKUYO | 3M可调，IPV6工业安全标准 3M adjustable IPV6 Industrial Safety Standard |
| 导航方式 Navigation mode | SLAM激光导航 SLAM laser navigation | 可选SLAM+末端反射板激光混合物导航SLAM End reflector laser mixture navigation is also available |
| 导航系统 guidance system | KH-Navikit® | |
| 地面越障高度 Ground obstacle crossing height | 5/10 | 满载/空载 |
| 举升高度 Lifting Height | 205mm | |
| 货叉提升速度 | 40/50 mm/s | 满载/空载 |
| 货叉下降速度 | 50/40 mm/s | 满载/空载 |
| 最大行驶速度 Maximum speed | 4.8/5.6 km/h | 满载/空载 |
| 最小转弯半径 minimum turning radius | 1750mm | |
| 最小通道宽度 Minimum channel width | 2500mm | |
| 续航时间 battery life | 6-8h | |
| 电池种类 Battery type | 铅酸电池 lead-acid battery | 可改为锂电池在线充电 online charging Lithium battery is also available |
| 工作区最大面积 Maximum area of work area | 160000㎡ | |
| 导航精度 navigation accuracy | ±10mm | |
